Revo 3

UNIQUE

The unique vertical arm design reduces drag to an absolute minimum. We believe that the airflow leaving the propellers has not been considered fully in current multirotor designs, which has driven us to produce a frame that is aerodynamic in forward flight while reducing the drag under the thrust column to an absolute minimum.

DYNAMIC

The greatly improved aerodynamics of the thrust column means a more agile platform, improved acceleration and cornering stability but also delivers better efficiency, resulting in increased battery life and a much quieter ride.

EXTREME

This radical design was in development for several months, requiring significant pilot testing and several design iterations to ensure appropriate strength and durability for what we believe is an extreme racing machine.

Package Contents:

1 x 3mm carbon upper arm
1 x 3mm carbon lower arm
1 x 2mm carbon top plate
1 x 2mm carbon bottom plate
1 x 1mm carbon FC cover

8 x stainless steel M2 x 8mm cap head screws
8 x stainless steel M2 plain nuts
4 x aluminium motor mounts
4 x aluminium tapered pillars
4 x brass standoffs
2 x stainless steel M3 nyloc nuts
10 x stainless steel M3 x 5mm button head screws

1 x sticker
1 x battery pad
1 x battery strap

Recommended Components:

Brother Hobby 1407 3600kv Motors
20 amp ESC’s
Furious FPV Piko BLX Flight Controller
RunCam Swift Mini
Any small VTX
Any small Receiver

Weight: 54 grams
Dimensions: 145 mm motor to motor
